2pcs NEW 10W TYT MD-UV390 PLUS AES256 Encryption DMR Digital Radio IP67 Waterproof Dual Band 136-174&400-480mhz Walkie Talkie Long Range
FAQ: How many versions are there?
ANSWERS:
1) Normal Encryption Series
MD-UV390 5W
MD-UV390 5W GPS
2) AES256 encryption Series
MD-UV390 Plus 5W
MD-UV390 Plus 5W GPS
MD-UV390 Plus 10W
MD-UV390 Plus 10W GPS
Note: if you need software, please contact us.
Factory 100% original product, please don’t to FLASH the machine privately, because the version of each machine is different.
Item number |
MD-UV390PLUS |
General |
|
FrequencyRange |
136-174Mhz &400-480MHz |
Channel No. |
3000 |
Antenna impedance |
50Ω |
Operating Voltage |
7.4 V DC |
Operating Temperature |
-30°C~+60°C |
Dimension(W x H x D) |
131x61x36mm |
Battery |
2200mAh Li-ion |
Transmitter |
|
Output power |
≤10W(H) ≤5W(L) |
Vocoder type |
TDMA |
Frequency Stability |
± 1.0 PPM |
Adjacent channel power |
≤-60dB |
Spurious Radiation |
Antenna:9KHz-1GHz ,≤ -36dBm 1GHz-12.75GHz ,≤-30dBm |
Hum and noise |
-40dB *12.5KHz |
4 FSK Digital Mode |
12.5KHz(data only):7k60FXD 12.5KHz(data+voice)7k60FXE |
Receiver |
|
Digital sensitivity |
0.25uV (BER 5%) |
Audio power |
1W |
Autio response |
=1dB-3dB |
Adjacent Channel Selectivity |
≤-60dB *12.5KHz |
